1 -1/2” In-Line Normally Closed Pyrotechnic Poppet Valve with Resettable Pin Puller Mechanism

TS-PY24F500-0400

Key Features

  • Efficient pyrotechnic actuation

  • Resettable design not based on frangible parent metal construction

  • High flow capacity

  • Normally closed

  • 500 psi MEOP

  • Lightweight – under 2 lbs

  • Service fluids: RP-1, N2O, GN2, GHe

Product Overview

The TS-PY24F500-0400 from Triton Space Technologies is a high-flow-rate, in-line pyrotechnically actuated poppet valve. Unlike conventional pyrotechnic valves, this valve does not rely on frangible, integrated, one-time-use parent metal construction. Rather, it is resettable, allowing for multiple actuations (after refurbishment). Intended for use as main propellant flow isolation on small-to-medium size liquid propulsion systems, this valve provides reliable, light-weight, fast-acting feed system isolation. The TS-PY24F500-0400 is purpose built for 21st century spaceflight feed systems. Contact us today for more information or to place your order.
